Suspension lowering module GLS x167 AMG 2023-2026 | plug-and-play system

Get full control of your Airmatic suspension. Fast, simple, and safe.

about the function

OBD Lowering Module for Mercedes x167 GLS AMG equipped with MBUX (NTG7) 2024-2026

Lower your Mercedes safely and instantly — no mechanical work.

Technical features

Compatible: Mercedes equipped with airmatic suspension 2023–2026

Module loads height profiles directly to the suspension ECU through the OBD‑II port.
Stores two presets:
1. Factory — automatically recorded on first connection
2. Low — default −20 mm (user‑selectable)
Available low offsets: −10mm, −20mm, −30mm, −40mm, −50mm, −60mm, −70 mm.
Switching or setting a new low profile takes ≈30 seconds. After programming, simply unplug and store the module.
The factory height is preserved and can be restored at any time by reconnecting the module.

Key benefits

DIY installation — no disassembly, no wiring, no soldering.No dealer or workshop visits required.
Fully reversible: module auto‑saves factory height on first use so you can restore OEM level anytime.
Leaves no trace and does not void factory warranty.
No phone or laptop required — settings written directly to the suspension ECU.The price includes activation for one car.
Provide the VIN(chassis) number to confirm compatibility with your Mercedes .
Get the look you want — fast, safe, and fully reversible.

Video description

payment

Suspension lowering module GLS x167 AMG 2023-2026 | plug-and-play system

The module adjusts the suspension’s zero(baseline) ride height.
All onboard suspension functions remain unchanged:
1)Sport mode still lowers the car by an additional −15 mm.
2)Raise button lifts the car by +25 mm from the lowered position.

Text the VIN(chassis) number to confirm compatibility with your Mercedes .

FROM:

900.00 $

reviews

frequent questions and answers:

Using the module is straightforward: plug it into the vehicle’s OBD2 port, choose the ride height, and you’re done—no additional tools or extra setup required.

Use the module only when required: connect to change or restore the ride height, then disconnect when finished.

You can lower the suspension up to 40mm and it’s safe for the ride and the suspension. If lower, it’s only for photos or short rides. We also recommend doing wheel alignment after lowering, if you ride below 35mm the tires will wear out faster without alignment.

No impact on the OEM warranty—there are no residual traces after removal.

Software-based adjustment is the safest method to lower the suspension.

No impact on the OEM warranty—there are no residual traces after removal.

still having questions?

INSTRUCTION:

to read

OBD Suspension Lowering Module — Setup Guide for Mercedes

Overview

Module stores 2 modes: “Low” and “Stock”.
Default Low = −20 mm.
Available steps: −10, −20, −30, −40, −50, −60, −70 mm (10 mm step).
After −70 mm cycle → −10 mm.

IMPORTANT: display indications may take up to 30 s to appear.

Preparation
Turn ignition on (press START/STOP twice) WITHOUT brake pedal .
Wait ~15 s for system boot. Insert the module into the OBD2 port.

How to set “Low” (default −20 mm) Insert module into OBD2.

Observe the central display: one BLUE blink = “Low” accepted.
Turn ignition off and remove module.
Start the car and close all doors — suspension will adjust to selected height.

How to return to stock settings

Repeat Preparation (ignition on, wait ~15 s, insert module).
Wait for two green blinks = stock settings accepted.
Turn ignition off, remove module, then start the car.
Suspension will return to FACTORY height .

How to change “Low” value (example −20 → −30 mm)

Turn ignition on (brake released), wait ~15 s.
Insert module and immediately PRESS and HOLD the brake pedal.
Observe central screen : two RED blinks = current value −20 mm;
after blinks finish,SHORT-press the brake once → display will blink three times RED = −30 mm.
each short press shifts value by −10 mm; after −70 mm the cycle returns to −10 mm.
Note: always wait for blinks to finish before the next press.

How to save selected value

When the display shows the required number of red blinks (e.g. 3 for −30 mm), press and hold the brake pedal.
Hold until the display blinks once BLUE = value saved as “Low”.
At this stage module will have following settings :
1) low -30mm
2) factory height

Turn ignition off and remove module.
Start the car and close doors — saved height will be applied.

Notes
Perform all actions with ignition on , engine is OFF . Do not act until display blinks complete. If indicators are missing or behavior is abnormal, contact support.

WhatsApp: +375298568502 .
