Suspension Lowering Module

MWM hand-held module for Mercedes w213 AMG E63 E63s

about the function

The MWM lowering module makes it possible to change the AIRMATIC suspension height. The unit allows to have full control suspension front and rear and adjust in 1mm increments.

In custom mode you can select any height in front and rear separately.
Min -70mm
Max +40mm
For example, you can select -29mm front and -27mm rear.

The lowering setting will be loaded via the ODB2 diagnostic port in the footwell of the car. After plugging the module into the OBD2, the menu will appear on the Mercedes Command screen. After changing and saving the settings, the suspension will adjust to the new height in 30 seconds. The factory setting will always be stored on the module and the user can set the suspension back to the factory setting. Once the settings are loaded, simply unplug and store for future use.

The price includes activation for one car.

Contact us in any convenient way from the Contact Us section, send the VIN number of your Mercedes to make sure that the module is compatible.

Video description

payment

Suspension Lowering Module

The suspension lowering software is always uploaded to separate module.
The other Mods for your Mercedes below can only be recorded on another module and you should pay extra $100 for the second module.
For 5+ Mods orders, we offer 10% discount.

FROM:

550.00 $

reviews

frequent questions and answers:

Can I drive a car with lowered suspension?

You can lower the suspension up to 40mm and it’s safe for the ride and the suspension. If lower, it’s only for photos or short rides. We also recommend doing wheel alignment after lowering, if you ride below 35mm the tires will wear out faster without alignment.

Does the car still change height when I change from Comfort to Sport+? 

The suspension will work as usual, but additionally lowered by the module. For example, as before, the suspension will become lower if you switch from Comfort to Sport+ mode (-15mm). If you lower the car by -30mm with the module, total lowering will be -45mm from factory Comfort mode. The same way "raise" button works.

Do I have to keep the module plugged in after lowering?

There is no need to keep the module plugged in all the time. You need to plug it in when you want to change the height or return to the factory height. Afterwards, disconnect the module. 

still having questions?

INSTRUCTION:

to read

1) start engine, close doors and turn on the radio

2) plug in the module to OBD2 diagnostic port and menu 1/2 appears on the screen
There are 3 basic modes:
– “factory” – the car will rise to the factory height
– “low” – factory minus 32mm in front and rear
– “custom” – factory minus the value that you select in the menu 2/2 (min -70mm, max +40mm, 1 step = 1 mm, front and rear separately)

3) spin a control knob under trackpad left / right to switch between modes in menu 1/2
To install “low” mode change “sel” to “low” and press the knob for confirmation
Important: don’t plug out the module from the OBD2 port until you receive “OK” message on the screen

3a) if you want to make your own height:
– tilt the knob up/down to switch to menu 2/2 “Edit custom mode” and press it
– spin the knob to choose the height and press it for confirmation
– in menu 1/2 change “sel” to “custom” and confirm choice

4) plug out the module
Important: don’t leave the module connected to the OBD2 port

We recommend making a wheel alignment after lowering to avoid increased tire wear, especially if you are going to drive below -40mm.
